Description: patient ECG cable, 10 leads, banana, clip, snap Din ends are available;
TPU flexible jacket, durable wires; fully compatible with original cable

Part No	Description
EKG-10024A	integrated; IEC, DB15M-Din3.0	Welch Allyn Cardioperfect MD
EKG-10024B	integrated; AHA, DB15M-Din3.0
EKG-10024C	integrated; IEC,DB15M-Banana4.0
EKG-10024D	integrated; AHA,DB15M-Banana4.0
EKG-10024E	integrated; IEC,DB15M-Clip end
EKG-10024F	integrated; AHA,DB15M-Clip end
EKG-10024G	integrated; IEC,DB15M-snap end
EKG-10024H	integrated; AHA,DB15M-snap end

EKG-10056A	integrated; IEC, Lemo 14P-Din3.0	Welch Allyn Cardioperfect Pro
EKG-10056B	integrated; AHA, Lemo 14P-Din3.0
EKG-10056C	integrated; IEC,Lemo 14P-Banana4.0
EKG-10056D	integrated; AHA,Lemo 14P-Banana4.0
EKG-10056E	integrated; IEC,Lemo 14P-Clip end
EKG-10056F	integrated; AHA,Lemo 14P-Clip end
EKG-10056G	integrated; IEC,Lemo 14P-snap end
EKG-10056H	integrated; AHA,Lemo 14P-snap end

Core technology:

1, All the leads we have longer length to coordinate with bigger size patients without difficulty.

2, the shileidng we have "Super-shield" technology to make it completely grounded and prevent any signal interference even in the complicated OR environment

3, the wires we use bigger size, very durable; surface is convenient for cleaning

4, the banana connector is specifically enhanced to make sure not signal loss even after long time usage.

compliance with
ANSI/AAMI EC53; ICE 60601-1 ISO10993-1 ISO 10993-5 ISO 10993-10

compatible welch allyn ten leads ECG cable cardioperfect pro; IEC color snap



MD patient cable connector

MD patient cable connector view

MD patient cable pinout
