Description: Connector: Artema/S&W special round 10 pin; five lead, electrode: 4.0snap
clips end also available
Cable material: TPU jacket shieded wires; cable length: 0.9meters for leads, 2.6 meters for main cable;

Compatible with: 8000 System, Diascope1,2 , Neoscope, DMS 700, defibrillator, Diascope-NT, Athena Systems, Cardio-Aid, DS Traveller, DSNT, DS1,DS2, MCX/LS

All the snap, clips even banana electrodes end are available. Lists of products code as following:

Part No	OEM No	Description
ECG-10015A		3-lead, AHA, Snap
ECG-10015B		3-lead, IEC, Snap
ECG-10015C		3-lead, AHA, Clip
ECG-10015D		3-lead, IEC, Clip
ECG-10015E		5-lead, AHA, Snap
ECG-10015F		5-lead, IEC, Snap
ECG-10015G		5-lead, AHA, Clip
ECG-10015H		5-lead, IEC Clip

compliance with: ANSI/AAMI EC53 ICE 60601-1 ISO 10993-1 ISO 10993-5 ISO 10993-10 RoHS

Core technology:

1, All the leads we have longer length to coordinate with bigger size patients without difficulty.

2, the shileidng we have "Super-shield" technology to make it completely grounded and prevent any signal interference even in the complicated OR environment

3, the wires we use bigger size, very robust and durable; surface is convenient for cleaning



compliance with ANSI/AAMI EC53 EN60601-1 ISO 10993-1 ISO 10993-5 ISO 10993-10

compliance with RoHS
