Compatible Datex-Ohmeda Three Lead ECG Leadwire

Application and Ordering Notes

This replacement ECG cable, trunk cable or leadwire set is intended for patient-monitor ECG signal connection. Please confirm the monitor model, lead count, lead color standard, and electrode terminal type before ordering.

Compatible with: GE Marquette: PRO1000 - Datex-ohmeda /:CH-S,CH-2S,CH-RS,CardiocapII,M- Estpr,OscarII,OSP-200,Satlite,ULTSVI,ULTSVO, ULTSIO,ULTS00,AS/3,CG-2CS,Anesthesia, CardiocapS/5,Compact,Critical Care, Original part number:545315 - Kontron:0754-000 IEC/AHA; clip/snap Original part number: 545315 545315-HEL 545317 AAMI 75cm, clips; 545327 AAMI 75cm, snap

Pansw also supply the following compatible parts but only on request: Replacement Clip – Leadwire, 300 Series

545344 Black LA, 75 cm/30 in. 545345 Brown V, 75 cm/30 in. 545346 Red LL, 125 cm/49 in. 545349 Green RL, 125 cm/49 in. Replacement Snap – Leadwire, 300 Series 545350 Red LL, 75 cm/30 in. Each 545351 Black LA, 75 cm/30 in. Each 545352 White RA, 75 cm/30 in. Each 545353 Brown V, 75 cm/30 in. Each 545354 Red LL, 125 cm/49 in. Each 545355 Green RL, 125 cm/49 in. Each Replacement Clip – Leadwire, 300 Series 545358 Red LL, 75 cm/30 in. Each 545359 White RA, 75 cm/30 in. Each 545365 Brown/yellow V2, 75 cm/30 in. Each 545366 Brown/green V3, 75 cm/30 in. Each 545367 Brown/blue V4, 75 cm/30 in. Each 545368 Brown/orange V5, 75 cm/30 in. Each 545369 Brown/violet V6, 75 cm/30 in. Each 8003274 Red LL, 1.5 m/60 in. Each 8003275 Brown V, 1.5 m/60 in. Each 8003276 Green RL, 1.5 m/60 in. Each 8003277 White RA, 1.5 m/60 in. Each 8003278 Black LA, 1.5 m/60 in.

IEC color connector view;

• All the leads we have longer length to coordinate with bigger size patients without difficulty.
• The shielding we have "Super-shield" technology to make it completely grounded and prevent any signal interference even in the complicated OR environment.
• The wires we use bigger size, very robust and durable; surface is convenient for cleaning.
