Description: connector: 12pin, three leads, electrode terminal:4.0 snap; TPU jacket wires; gold plated connector pins; integrated cable from machine to patients;

Compatible with: bruker ODAM defiguard 3002

Pansw supplies Bionet cable with 5 leads, 3 leads, snaps end, clips even banana end upon request; Also we provide ECG trunk cables for LL style, DIN style or HP AA style; Please refer to the list following for the detailed products models;

ECG-10075A	3-lead, AHA, Snap
ECG-10075B	3-lead, IEC, Snap
ECG-10075C	3-lead, AHA, Clip
ECG-10075D	3-lead, IEC, Clip

compliance with: ANSI/AAMI EC53 ICE 60601-1 ISO 10993-1 ISO 10993-5 ISO 10993-10 RoHS

connector view

Core technology:

1, All the leads we have longer length to coordinate with bigger size patients without difficulty.

2, the shileidng we have "Super-shield" technology to make it completely grounded and prevent any signal interference even in the complicated OR environment

3, the wires we use bigger size, very robust and durable; surface is convenient for cleaning

compliance with ANSI/AAMI EC53 EN60601-1 ISO 10993-1 ISO 10993-5 ISO 10993-10

compliance with RoHS
