Picture 1: general view of USB TRIM datawire

PanSW part code:

Description: data wire for HP trim ECG acquisition box;
cable length: 1.8 meters; cable material: TPU jacket wire; both connectors with soft relief; both connector with ferrite bead to suppress electronic noise;
compatible with: Pagewriter Touch (860284) – Pagewriter Trim Ⅰ,Ⅱ,Ⅲ (860286-860287–860288–860290)
Use with HP trim leadwire set

compliance with
ANSI/AAMI EC53; ICE 60601-1 ISO10993-1 ISO 10993-5 ISO 10993-10

picture 2: connector view

Picture 3: ferrite bead and soft relief
